1. Product use
Capacitors in this manual are shunt capacitor units (hereinafter referred to as capacitors) applicable to AC power systems with nominal voltage above 1kV and frequency of 50 or 60Hz, which are used to improve power factor and grid quality. The product adopts GB/T 11024.1 and DL/T 840 standard.
2. Product model and meaning

高压并联电容器

For example:
BAM12-500-1 w
Description: Single phase outdoor shunt capacitor made of benzyl-toluene impregnated polypropylene film medium, rated voltage 12kV, rated capacity 500kvar3. Product structure
The capacitor is mainly composed of three parts: case, core and impregnating agent. The shell is made of high quality sheet steel bent and sealed by welding. The cover of the case is welded with the lead line sleeve, and the two sides of the case are welded with the hoist for handling and installation. The core consists of a number of components and insulating parts connected in series and parallel. The components are made of polypropylene film as solid medium, aluminum foil as plate, and the case is filled with excellent impregnating agent.
4. Conditions of use
4.1 Environment and Operating Conditions:
a. The altitude of the area to be used is not more than 1000m.
b. Ambient temperature: -40 ℃ ~ +45℃.
c. The site shall be free from violent mechanical vibration, harmful gas and steam, and conductive or explosive dust.
4.2 Other Conditions of Use:
Before the capacitor is put into operation, the remaining voltage between terminals shall not exceed 10% of the rated voltage.
4.3 When the capacitor involves high relative humidity, rapid mold growth, corrosive atmosphere, pollution, altitude over 1000m
In case of any special use conditions such as earthquake area, the Buyer shall notify the Company and determine the type of product and special preventive measures to be taken through negotiation.
5. Rating and main technical performance
5.1 Rated voltage:
1.05; 3.15; 6.6/√3; 6.3; 10.5/√3; 10.5; 11/√3; 11; 11/2; 12/2; 12/√3; 12; 24/√3; 24kV.
5.2 Rated Capacity:
100; 150; 200; 300; 334; 400; 417; 500; 667kvar.
5.3 Product Technical specifications (see Appendix A).
5.4 Product and Installation dimensions (see Appendix B).
5.5 Capacitance deviation:
The deviation between the measured capacitance and the rated value of the capacitor should not exceed -5 ~ +5% of the rated value; For three-phase capacitors, the ratio of the maximum to the minimum capacitance measured between any two terminals should not exceed 1.02.
5.6 At rated voltage and temperature 20℃, capacitor loss Angle tangent (tanδ) value, full-film dielectric capacitor shall not exceed 0.0005.
5.7 Capacitor terminal can withstand 2.15 times the rated voltage of power frequency AC experimental voltage test, lasted for 10s.
5.8 For all capacitors whose terminals are insulated from the housing, the short-time power frequency withstand voltage test and lightning impulse voltage test of the insulation level corresponding to the rated voltage of the capacitor in Table 1 can be carried out between the terminals and the housing for 10s. A capacitor with a terminal fixed to the housing is not tested.

Table 1 Insulation level kV

Rated voltage of capacitor kV	Insulation grade kV	The average root value of short-time power frequency withstand voltage (wet test/dry test) lasted for 10s	Lightning impulse voltage 1.2-5/50μs peak positive and negative polarity 15 times
3.15	3	18/25	40
6.6/√3；6.3	6	23/30	60
10.5/√3；10.5；11/√3；11；11/2；12/2；12/√3；12	10	30/42	75
24；24/√3	20	50/65	125

5.9 Overloading capacity

a. Overvoltage: Capacitors should be able to operate at the voltage levels given in Table 2. However, the total number of overvoltages above 1.15UN given in Table 2 should not exceed 500 times during the lifetime of the capacitor.

Table 2 Allowed voltage levels in operation

Type	Voltage factor x UN (square mean root)	Maximum duration	Description
Power frequency	1.00	continuity	The highest average value of a capacitor during any period of operation
Power frequency	1.10	12 hours every 24 hours	System voltage adjustment and fluctuation
Power frequency	1.15	30 minutes every 24 hours	System voltage adjustment and fluctuation
Power frequency	1.20	5min	Voltage increases under light load
Power frequency	1.30	1min	Voltage increases under light load
Power frequency plus harmonics	Keep the current within the value given in clause 5.9b

b. Overcurrent: The capacitor shall be able to operate under continuous overcurrent not exceeding 1.3 times the rated current of the capacitor caused by fundamental overvoltage or harmonics or both. For capacitors with a maximum actual capacitance of 1.05 times the rated capacitance, the continuous overcurrent is allowed to reach 1.37 times the rated current.

高压并联电容器

Appendix A: Product technical parameters

No.	Model	Rated voltage (kV)	Rated capacity (kvar)	Rated capacitance (μF)	Overall dimensions（mm）										Weight （kg）	Drawing No
No.	Model	Rated voltage (kV)	Rated capacity (kvar)	Rated capacitance (μF)	L0	L	L1	L2	H0	H	H1	F	W	W1	Weight （kg）	Drawing No
1	BFM6.6/√3-50-1W	6.6/√3	50	11.0	370	310	400		150	280	490	200	110		18	1
2	BFM6.6/√3-100-1W	6.6/√3	100	21.9	440	380	470		230	360	570	250	120		28	1
3	BFM6.6/√3-200-1W	6.6/√3	200	43.8	560	500	590		230	360	570	320	165		45	1
4	BAM6.6/√3-200-1W	6.6/√3	200	43.8	431	383	473		260	390	620	250	163		39	2
5	BAM6.6/√3-334-1W	6.6/√3	334	73.2	431	383	473		440	570	800	250	163		56	2
6	BAM6.6/√3-400-1W	6.6/√3	400	87.7	431	383	473		500	630	860	250	179		64	2
7	BAM6.6/√3-417-1W	6.6/√3	417	91.4	431	383	473		530	660	890	250	179		67	2
8	BFM11/√3-50-1W	11/√3	50	3.95	370	310	400		150	280	530	200	110		18	1
9	BFM11/√3-100-1W	11/√3	100	7.89	440	380	470		230	360	610	250	120		28	1
10	BFM11/√3-200-1W	11/√3	200	15.8	560	500	590		230	360	610	320	165		45	1
11	BAM11/√3-200-1W	11/√3	200	15.8	431	383	473		260	390	700	250	163		39	2
12	BAM11/√3-334-1W	11/√3	334	26.4	431	383	473		440	570	880	250	163		56	2
13	BAM11/√3-400-1W	11/√3	400	31.6	431	383	473		500	630	940	250	179		64	2
14	BAM11/√3-417-1W	11/√3	417	32.9	431	383	473		530	660	970	250	179		67	2
15	BAM11/√3-500-1W	11/√3	500	39.5	431	383	473		630	760	1070	250	179		77	2
16	BAM11/2√3-334-1W	11/2√3	334	105.4	431	383	473		440	570	880	250	163		59	2
17	BAM11/2√3-400-1W	11/2√3	400	126.3	431	383	473		500	630	940	250	179		67	2
18	BAM11/2√3-417-1W	11/2√3	417	131.6	431	383	473		530	660	1070	250	179		70	2
19	BAM11/2-334-1W	11/2	334	35.1	431	383	473		440	570	880	250	163		56	2
20	BAM11/2-400-1W	11/2	400	42.1	431	383	473		500	630	940	250	179		64	2
21	BAM11/2-417-1W	11/2	417	43.9	431	383	473		530	660	970	250	179		67	2
22	BAM11/2-500-1W	11/2	500	52.6	431	383	473		630	760	1070	250	179		77	2
23	BFM11-50-1W	11	50	1.32	370	310	400		150	280	530	200	110		18	1
24	BFM11-100-1W	11	100	2.63	440	380	470		230	360	610	250	120		28	1
25	BFM11-200-1W	11	200	5.26	560	500	590		230	360	610	320	165		45	1
26	BAM11-200-1W	11	200	5.26	431	383	473		260	390	700	250	163		39	2
27	BAM11-334-1W	11	334	8.79	431	383	473		440	570	880	250	163		56	2
28	BAM11-400-1W	11	400	10.5	431	383	473		500	630	940	250	179		64	2
29	BAM11-417-1W	11	417	11.0	431	383	473		530	660	970	250	179		67	2
30	BAM11-500-1W	11	500	13.2	431	383	473		630	760	1070	250	179		77	2
31	BFM12/√3-50-1W	12/√3	50	3.32	370	310	400		150	280	530	200	110		18	1
32	BFM12/√3-100-1W	12/√3	100	6.63	440	380	470		230	360	610	250	120		28	1
33	BFM12/√3-200-1W	12/√3	200	13.3	560	500	590		230	360	610	320	165		45	1
34	BAM12/√3-200-1W	12/√3	200	13.3	431	383	473		260	390	700	250	163		39	2
35	BAM12/√3-334-1W	12/√3	334	22.2	431	383	473		440	570	880	250	163		56	2
36	BAM12/√3-400-1W	12/√3	400	26.5	431	383	473		500	630	940	250	179		64	2
37	BAM12/√3-417-1W	12/√3	417	27.7	431	383	473		530	660	970	250	179		67	2
38	BAM12/√3-500-1W	12/√3	500	33.2	431	383	473		630	760	1070	250	179		77	2
39	BAM12/2√3-334-1W	12/2√3	334	88.6	431	383	473		440	570	880	250	163		59	2
40	BAM12/2√3-400-1W	12/2√3	400	106.1	431	383	473		500	630	940	250	179		67	2
41	BAM12/2√3-417-1W	12/2√3	417	110.6	431	383	473		530	660	1070	250	179		70	2
42	BAM12/2-334-1W	12/2	334	29.5	431	383	473		440	570	880	250	163		56	2
43	BAM12/2-400-1W	12/2	400	35.4	431	383	473		500	630	940	250	179		64	2
44	BAM12/2-417-1W	12/2	417	36.9	431	383	473		530	660	970	250	179		67	2
45	BAM12/2-500-1W	12/2	500	44.2	431	383	473		630	760	1070	250	179		77	2
46	BFM12-50-1W	12	50	1.11	370	310	400		150	280	530	200	110		18	1
47	BFM12-100-1W	12	100	2.21	440	380	470		230	360	610	250	120		28	1
48	BFM12-200-1W	12	200	4.42	560	500	590		230	360	610	320	165		45	1
49	BAM12-200-1W	12	200	4.42	431	383	473		260	390	700	250	163		39	2
50	BAM12-334-1W	12	334	7.38	431	383	473		440	570	880	250	163		56	2
51	BAM12-400-1W	12	400	8.84	431	383	473		500	630	940	250	179		64	2
52	BAM12-417-1W	12	417	9.22	431	383	473		530	660	970	250	179		67	2
53	BAM12-500-1W	12	500	11.1	431	383	473		630	760	1070	250	179		77	2
54	BAM22/2√3-334-1W	22/2√3	334	26.4	431	383	473		460	590	960	250	163		58	2
55	BAM22/2√3-400-1W	22/2√3	400	31.6	431	383	473		520	650	1020	250	179		66	2
56	BAM22/2√3-417-1W	22/2√3	417	32.9	431	383	473		550	680	1050	250	179		69	2
57	BAM22/2√3-500-1W	22/2√3	500	39.5	431	383	473		650	780	1150	250	179		79	2
58	BAM24/2√3-334-1W	24/2√3	334	22.2	431	383	473		460	590	960	250	163		58	2
59	BAM24/2√3-400-1W	24/2√3	400	26.5	431	383	473		520	650	1020	250	179		66	2
60	BAM24/2√3-417-1W	24/2√3	417	27.7	431	383	473		550	680	1050	250	179		69	2
61	BAM24/2√3-500-1W	24/2√3	500	33.2	431	383	473		650	780	1150	250	179		79	2
62	BFM6.6-100-3W	6.6	100	7.31	715	665	755	725	230	370	620	250	120		47	3
63	BFM6.6-200-3W	6.6	200	14.6	715	665	755	725	230	370	620	250	165	80	56	3
64	BFM6.6-300-3W	6.6	300	21.9	715	665	755	725	230	370	620	250	200	80	72	3
65	BFM11-100-3W	11	100	2.63	715	665	755	725	230	370	620	250	120		47	3
66	BFM11-200-3W	11	200	5.29	715	665	755	725	230	370	620	250	165	80	56	3
67	BFM11-300-3W	11	300	7.89	715	665	755	725	230	370	620	250	200	80	72	3
68	BFM12-100-3W	12	100	2.21	715	665	755	725	230	370	620	250	120		47	3
69	BFM12-200-3W	12	200	4.42	715	665	755	725	230	370	620	250	165	80	56	3
70	BFM12-300-3W	12	300	6.63	715	665	755	725	230	370	620	250	200	80	72	3
